If your Motorola Moto G14 is stuck at boot logo, Reset FRP, Screen lock or repair OS using any UFS & EMMC repair tool. This guide, we will covered Motorola Moto G14 UFS ISP pinout & Test Point to quickly fix the issue and repair the phone easily.
Read: Moto G14 2024 SEC Dead Repair File
What is ISP Pinout?
ISP (In-System Programming) allows flash chip to be programmed without removing it from the PCB. It uses a specific pinout and protocol to communicate with computer.
A test point is a copper points on a PCB that allows you to boot the phone into the emergency download mode to perform flashing, unlocking or repairing the phone.
Read more: Bypass Google FRP Lock on Motorola Moto G14
Motorola Moto G14 UFS ISP PinOUT & Test Point Image:
Below, we provide ISP and Test Point Methods to carefully boot your device into Flash Mode. So, follow the below methods to successfully Reboot your Motorola Moto G14 to SPD Flash Mode.
Read more: Bypass Google FRP Lock on Motorola Moto Tab G62
Do check: Redmi A5 EMMC ISP PinOUT & Test Point
EMMC ISP Pin Labels You Need:
- CLK
- TXOP
- TXON
- RXOP
- RXON
- GND – Ground
Also read: Honor X9a EDL Test Point
Tip: You can use a microscope or a 10x magnifier to identify the points correctly.
Also read: Huawei Nova 12 Lite EDL Test Point
Required Tools for ISP Pinout Method
Make sure your workstation includes:
- UFI Box, Easy JTAG Plus, or Medusa Pro
- 0.1mm – 0.3mm jumper wires
- Fine-tip soldering iron
- Soldering flux
- Isopropyl Alcohol (IPA 99%)
- Multimeter
- Microscope or magnifier
Also read: Vivo Y29 5G EMMC ISP PinOUT
How to Connect ISP to EMMC Box
- Open the back panel of the Motorola Moto G14
- Disassemble the phone.
- Locate the eMMC chip area on the PCB.
- Find & Solder to ISP Points
- Use the above diagram to identify these pins: CLK, TXON, TXOP, GND, and RXON, RXOP.
- Motorola Moto G14 UFS ISP PinOUT & Test Point to Hard Reset, FRP Bypass or Flash firmware.
Also read: Moto G54 5G Test point
- Or, you can use the test points.
- Connect to UFI or Easy JTAG,
- In the UFI or Easy Jtag Software:
- Click Identify eMMC
- Bypass FRP: Navigate to: User Partition – Special Task – Reset FRP
- Fix Dead Boot: Select the firmware & click flash.
- That’s it.
Also: Realme C55 EMMC ISP PinOUT
Warning: Shorting the wrong test or ISP points can damage your Motorola Moto G14. Please proceed carefully!
