If your Realme C61 is stuck at bootlogo, dead, or FRP or Screen lock pattern, password, pin lock using any EMMC repair tool. This guide, we will show you Realme C61 EMMC ISP pinout & Test Point to quickly fix the issue and repair the phone easily.
Also read: Realme C61 RMX3933 Dead & Baseband Repair File
What is ISP Pinout?
ISP (In-System Programming) allows flash chip to be programmed without removing it from the PCB. It uses a specific pinout and protocol to communicate with computer.
Read more: Hard Reset Realme C61
The latest Realme C61 powered-by SPD Unisoc Tiger T612 SOC’s & comes with locked USB & bootloader. So, it is impossible to boot the device into Download mode without authorization.
Read more: Bypass Google Gmail FRP Lock on Realme C61
Realme C61 ISP PinOUT | Test Point Image:
The Realme C61 ISP pinout enables the Preloader & Brom mode for flash stock ROM, bypass FRP lock, or reset userdata, etc without out removing EMMC chip by using any Easyjtag, or any UFS and EMMC repair tool.
Also read: How to Enter Download or EDL Mode on Oppo Phone
EMMC ISP Pin Labels You Need:
- CMD – Command Line
- CLK – Clock
- DAT0 – Data line 0
- VCC / VCCQ – Power supply for EMMC
- GND – Ground
Do check: Realme C63 Dead & Baseband Repair File
Tip: You can use a microscope or a 10x magnifier to identify the points correctly.
Also read: Moto G84 EDL Test Point
Required Tools for ISP Pinout Method
Make sure your workstation includes:
- UFI Box, Easy JTAG Plus, or Medusa Pro
- 0.1mm – 0.3mm jumper wires
- Fine-tip soldering iron
- Soldering flux
- Isopropyl Alcohol (IPA 99%)
- Multimeter
- Microscope or magnifier
Also read: Realme Narzo N61 Test Point
How to Connect ISP to EMMC Box
- Open the back panel of the Realme C61
- Disassemble the phone.
- Locate the eMMC chip area on the PCB.
- Find & Solder to ISP Points
- Use the above diagram to identify these pins: CLK, CMD, DATA0, GND, VCCQ, VCC.
- Realme C61 ISP EMMC PinOUT to Hard Reset, FRP Bypass or Flash firmware.
Also read: Realme 12 5G UFS ISP PinOUT
- Or, you can use the test points.
- Connect to UFI or Easy JTAG,
- In the UFI or Easy Jtag Software:
- Click Identify eMMC
- Bypass FRP: Navigate to: User Partition – Special Task – Reset FRP
- Fix Dead Boot: Select the firmware & click flash.
- That’s it.
Also read: Realme 11 5G EMMC ISP PinOUT
Warning: Shorting the wrong test or ISP points can damage your Realme C61. Please proceed carefully!
