If your Realme 11 5G MTK smartphone is Bricked, Forget pattern lock, or you are not able to unlock FRP. This page, we will show you Realme 11 5G Test Point & ISP EMMC pinout to quickly fix the issue and repair the phone easily.
The pinout enables the Preloader & Brom mode for flash stock ROM, bypass FRP lock, or reset userdata, etc using any tool.
What is ISP Pinout?
ISP (In-System Programming) allows flash chip to be programmed without removing it from the PCB. It uses a specific pinout and protocol to communicate with computer.
A test point is a copper points on a PCB that allows you to boot the phone into the emergency download mode to perform flashing, unlocking or repairing the phone.
Read more: Samsung Galaxy A71 SM-A715F EDL Point
The latest Realme 11 5G powered-by MTK SOC’s & comes with locked USB & bootloader. So, it is impossible to boot the device into Download mode without authorization.
Read more: Vivo Y35 Hard Reset & Factory Reset
Realme 11 5G ISP EMMC Pinout | Test Point Image:
Here we provide ISP and Test Point Methods to carefully boot your device into Flash Mode. So, follow the below methods to successfully Reboot your Realme 11 5G to MTK ISP Mode.
Also read: How to Enter Download or EDL Mode on Oppo Phone
More: QPST Tool – Qualcomm QPST Flash Tool Download Latest All Version
EMMC ISP Pin Labels You Need:
- CMD – Command Line
- CLK – Clock
- DAT0 – Data line 0
- VCC / VCCQ – Power supply for EMMC
- GND – Ground
Tip: You can use a microscope or a 10x magnifier to identify the points correctly.
Required Tools for ISP Pinout Method
Make sure your workstation includes:
- UFI Box, Easy JTAG Plus, or Medusa Pro
- 0.1mm – 0.3mm jumper wires
- Fine-tip soldering iron
- Soldering flux
- Isopropyl Alcohol (IPA 99%)
- Multimeter
- Microscope or magnifier
How to Connect ISP to EMMC Box
- Open the back panel of the Realme 11 5G
- Disassemble the phone.
- Locate the eMMC chip area on the PCB.
- Find & Solder to ISP Points
- Use the above diagram to identify these pins: CLK, CMD, DATA0, GND, VCCQ, VCC.
- Realme 11 5G ISP EMMC PinOUT to Hard Reset, FRP Bypass or Flash firmware.
- Or, you can use the test points.
- Connect to UFI or Easy JTAG,
- In the UFI or Easy Jtag Software:
- Click Identify eMMC
- Bypass FRP: Navigate to: User Partition – Special Task – Reset FRP
- Fix Dead Boot: Select the firmware & click flash.
- That’s it.
Also: Vivo Y200 FRP Unlock/Bypass Google Verification
Warning: Incorrectly shorting test points can damage the Realme 11 5G. Proceed with caution!
